Description
Frameset
| Frame | Alpha Gold Aluminium, rack and mudguard mounts, DuoTrap S-compatible, IS disc-brake mount, 135×5 mm QR |
|---|---|
| Fork | Verve Steel, threaded steel steerer, IS-disc mount, 460 mm axle-to-crown, 100×5 mm QR |
Wheels
| Hub front | Formula DC-20, alloy, 6-bolt, 5×100 mm QR |
|---|---|
| Skewer front | 100×5 mm QR |
| Hub rear | Formula DC-31, alloy, 6-bolt, 6/7/8-speed freewheel, 135×5 mm QR |
| *Skewer rear | Size: S, M, L, XL 156×5 mm QR |
| Size: S, M, L, XL 152×5 mm QR |
|
| *Rim | Size: S, M, L, XL Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve |
| Size: S, M, L, XL Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
|
| Spokes | 14 g stainless steel |
| *Tyre | Size: S, M, L, XL Bontrager H5 Comp, wire bead, 30 tpi, 700×45 mm |
| Size: S, M, L, XL Bontrager H5, wire bead, 30 tpi, 700×45 mm |
|
| Max tyre size | 700x45mm with or without mudguards |
Drivetrain
| *Shifter | Size: S, M, L, XL Shimano Altus EF500, 7-speed |
|---|---|
| Size: S, M, L, XL Shimano Altus EF500, 3-speed |
|
| Front derailleur | Shimano Tourney TY510, 34.9 mm clamp, top swing, dual pull |
| Rear derailleur | Shimano Altus M310 |
| Crank | Forged alloy, 48/38/28, chainguard, 170 mm length |
| *Bottom bracket | Size: S, M, L, XL Sealed cartridge, 68 mm |
| Size: S, M, L, XL Sealed bearing, 68 mm threaded |
|
| Cassette | 14-34t, 7-speed freewheel |
| Chain | KMC Z7 |
| Pedal | Wellgo nylon platform |
Components
| Saddle | Bontrager Boulevard |
|---|---|
| Seatpost | Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
| Handlebar | Trek Urban, alloy, 25.4 mm, comfort sweep, 45 mm rise, 620 mm width |
| Grips | Bontrager Satellite |
| *Stem | Size: S, M, L, XL Bontrager Quill, 25.4 mm clamp, 25-degree rise, 100 mm reach |
| Size: S, M, L, XL Bontrager quill, 25.4 mm clamp, 25-degree, 105 mm length |
|
| Head set | 1-1/8″ threaded, semi-integrated, semi-cartridge bearings |
| Brake | Tektro MD-M280 mechanical disc, 160 mm rotor |
Weight
| Weight | M – 14.10 kg / 31.08 lb |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
