Specifications
Frameset
| Frame | Alpha Gold Aluminium, rack and mudguard mounts, DuoTrap S-compatible, IS disc-brake mount, 135×5 mm QR |
|---|---|
| Fork | Verve Steel, threaded steel steerer, IS-disc mount, 460 mm axle-to-crown, 100×5 mm QR |
Wheels
| Hub front | Formula DC-20, alloy, 6-bolt, 5×100 mm QR |
|---|---|
| Skewer front | 100×5 mm QR |
| Hub rear | Formula DC-31, alloy, 6-bolt, 6/7/8-speed freewheel, 135×5 mm QR |
| *Skewer rear | Size: S, M, L, XL 156×5 mm QR |
| Size: S, M, L, XL 152×5 mm QR |
|
| *Rim | Size: S, M, L, XL Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve |
| Size: S, M, L, XL Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
|
| Spokes | 14 g stainless steel |
| *Tyre | Size: S, M, L, XL Bontrager H5 Comp, wire bead, 30 tpi, 700×45 mm |
| Size: S, M, L, XL Bontrager H5, wire bead, 30 tpi, 700×45 mm |
|
| Max tyre size | 700x45mm with or without mudguards |
Drivetrain
| *Shifter | Size: S, M, L, XL Shimano Altus EF500, 7-speed |
|---|---|
| Size: S, M, L, XL Shimano Altus EF500, 3-speed |
|
| Front derailleur | Shimano Tourney TY510, 34.9 mm clamp, top swing, dual pull |
| Rear derailleur | Shimano Altus M310 |
| Crank | Forged alloy, 48/38/28, chainguard, 170 mm length |
| *Bottom bracket | Size: S, M, L, XL Sealed cartridge, 68 mm |
| Size: S, M, L, XL Sealed bearing, 68 mm threaded |
|
| Cassette | 14-34t, 7-speed freewheel |
| Chain | KMC Z7 |
| Pedal | Wellgo nylon platform |
Components
| Saddle | Bontrager Boulevard |
|---|---|
| Seatpost | Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
| Handlebar | Trek Urban, alloy, 25.4 mm, comfort sweep, 45 mm rise, 620 mm width |
| Grips | Bontrager Satellite |
| *Stem | Size: S, M, L, XL Bontrager Quill, 25.4 mm clamp, 25-degree rise, 100 mm reach |
| Size: S, M, L, XL Bontrager quill, 25.4 mm clamp, 25-degree, 105 mm length |
|
| Head set | 1-1/8″ threaded, semi-integrated, semi-cartridge bearings |
| Brake | Tektro MD-M280 mechanical disc, 160 mm rotor |
Weight
| Weight | M – 14.10 kg / 31.08 lb |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
