Specifications
- Frame
-
Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142×12 mm thru axle
- Fork
-
Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12×100 mm thru axle
- Weight
- 56 – 9.10 kg / 20.07 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lbs).
- Shifter
-
Shimano 105 R7020, 11-speed
- Front derailleur
-
Shimano 105 R7000, braze-on
- Rear derailleur
-
Shimano 105 R7000, short cage, 30T max cog
- *Crank
-
Size: 47, 50, 52, 54
Shimano 105 R7000, 50/34 (compact), 165 mm lengthSize: 56, 58
Shimano 105 R7000, 50/34 (compact), 175 mm length - Bottom bracket
- Cassette
-
Shimano 105 R7000, 11-30, 11 speed
- Chain
-
Shimano 105 HG601, 11-speed
- Max. chainring size
- 1x: 50T, 2x: 53/39
- Hub front
-
Formula RX-512 alloy, 6-bolt, 100×12 mm thru axle
- Skewer front
- Hub rear
-
Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142×12 mm thru axle
- Skewer rear
- Rim
-
Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve
- Spokes
-
14 g stainless steel, black
- *Tyre
-
Size: 47, 50, 52, 54, 56, 58
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700×28 mmSize: 47, 50, 52, 54, 56, 58
Bontrager Aeolus Comp, Hardcase Lite, wire bead, 60 tpi, 700×28 mm - Max tyre size
- 28 mm (as measured, see manual for details)
- Saddle
- *Seatpost
-
Size: 47, 50, 52, 54
Bontrager alloy seat mast cap, 10 mm offset, short lengthSize: 56, 58
Bontrager alloy seat mast cap, 10 mm offset, tall length - *Handlebar
-
Size: 47, 50, 52
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop widthSize: 54, 56, 58
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width - Handlebar tape
-
Bontrager Supertack Perf tape
- *Stem
-
Size: 58
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110mm length - Brake rotor
-
Tektro, 6-bolt, 160mm
- Rotor size
- Max brake rotor sizes: 160 mm front and rear
-
Sizing
size-table Size Rider Height Inseam 47 152 – 158 cm
5’0″ – 5’2″
71 – 75 cm
28″ – 30″
50 158 – 163 cm
5’2″ – 5’4″
74 – 77 cm
29″ – 30″
52 163 – 168 cm
5’4″ – 5’6″
76 – 79 cm
30″ – 31″
54 168 – 174 cm
5’6″ – 5’9″
78 – 82 cm
31″ – 32″
56 174 – 180 cm
5’9″ – 5’11”
81 – 85 cm
32″ – 33″
58 180 – 185 cm
5’11” – 6’1″
84 – 87 cm
33″ – 34″
60 185 – 190 cm
6’1″ – 6’3″
86 – 90 cm
34″ – 35″
62 190 – 195 cm
6’3″ – 6’5″
89 – 92 cm
35″ – 36″
Geometry
Geometry diagram labelling frame measurements A to N. Each label corresponds to a row in the geometry table below.
All measurements provided in cm unless otherwise stated.
| Frame size number | Wheel size | A — Seat tube | B — Seat tube angle | C — Head tube length | D — Head angle | E — Effective top tube | G — Bottom bracket drop | H — Chainstay length | I — Offset | J — Trail | K — Wheelbase | L — Standover | M — Frame reach | N — Frame stack | Saddle rail height min (w/short mast) | Saddle rail height max (w/short mast) | Saddle rail height min (w/tall mast) | Saddle rail height max (w/tall mast) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47cm | 700c | 42.4 | 74.6° | 10.0 | 72.1° | 51.2 | 7.2 | 41.0 | 4.5 | 6.8 | 97.2 | 69.2 | 37.3 | 50.7 | 55.5 | 61.5 | 59.0 | 65.0 |
| 50cm | 700c | 45.3 | 74.6° | 11.1 | 72.1° | 52.1 | 7.2 | 41.0 | 4.5 | 6.2 | 97.4 | 71.1 | 37.8 | 52.1 | 58.5 | 64.5 | 62.0 | 68.0 |
| 52cm | 700c | 48.3 | 74.2° | 12.1 | 72.8° | 53.4 | 7.2 | 41.0 | 4.5 | 5.8 | 97.7 | 73.2 | 38.3 | 53.3 | 61.5 | 67.5 | 65.0 | 71.0 |
| 54cm | 700c | 49.6 | 73.7° | 13.1 | 73.0° | 54.3 | 7.0 | 41.0 | 4.5 | 5.6 | 98.1 | 74.4 | 38.6 | 54.1 | 64.0 | 70.0 | 67.5 | 73.5 |
| 56cm | 700c | 52.5 | 73.3° | 15.1 | 73.5° | 55.9 | 7.0 | 41.0 | 4.0 | 5.8 | 98.3 | 76.8 | 39.1 | 56.3 | 67.0 | 73.0 | 70.5 | 76.5 |
| 58cm | 700c | 55.3 | 73.0° | 17.1 | 73.8° | 57.4 | 6.8 | 41.1 | 4.0 | 5.7 | 99.2 | 79.3 | 39.6 | 58.1 | 69.0 | 75.0 | 72.5 | 78.5 |
