Specifications
Frameset
| Frame | Alpha Gold Aluminium, DuoTrap S-compatible, internal cable routing, flat-mount disc, rack and mudguard mounts, 135×5 mm QR |
|---|---|
| Fork | FX Carbon, rack and mudguard mounts, flat-mount disc, 405 mm axle-to-crown. ThruSkew 5 mm QR |
Wheels
| Hub front | Formula DC-20, alloy, 6-bolt, 5×100 mm QR |
|---|---|
| Skewer front | 130×5 mm QR, ThruSkew |
| Hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm QR |
| Skewer rear | 152×5 mm QR |
| Rim | Bontrager Tubeless Ready Disc, 32-hole, Presta valve |
| Tyre | Bontrager H2 Comp, wire bead, 30 tpi, 700×32 mm |
| Max tyre size | 700x38mm without mudguards, 700x35mm with mudguards |
Drivetrain
| Shifter | Shimano Deore M4100, 10-speed |
|---|---|
| Rear derailleur | Shimano Deore M5120, long cage |
| *Crank | Size: XS, S, M Prowheel alloy, 40T narrow-wide ring, 170 mm length |
| Size: L, XL, XXL Prowheel alloy, 40T narrow-wide ring, 175 mm length |
|
| Cassette | Shimano Deore M4100, 11-46, 10-speed |
| Chain | KMC X10, 10-speed |
| Pedal | Bontrager City pedals |
| Max. chainring size | 1x: 42T, 2x/3x: 48T |
Components
| Saddle | Bontrager H1 |
|---|---|
| Seatpost | Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
| *Handlebar | Size: XS, S, M Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 600 mm width |
| Size: L, XL, XXL Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 660 mm width |
|
| Grips | Bontrager Satellite IsoZone Plus, lock-on, ergonomic |
| *Stem | Size: XS, S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length |
| Size: M, L, XL, XXL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
|
| Head set | 1 1/8″ steel threadless |
| Brake | Shimano hydraulic disc, MT201 lever, UR300 calliper |
| Brake rotor | Shimano RT26, 6-bolt,160 mm |
| Rotor size | Max brake rotor sizes: 160mm front & rear |
Weight
| Weight | M – 11.38 kg / 25.09 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
