Specifications
Frameset
| Frame | 100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, flat-mount disc, UDH, 142×12 mm thru axle |
|---|---|
| Fork | Domane AL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
Weight
| Weight | 56 – 10.35 kg / 22.82 lb |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
Drivetrain
| Shifter | Shimano Tiagra R4720, 10-speed |
|---|---|
| Front derailleur | Shimano Tiagra 4700, 31.8 mm clamp |
| Rear derailleur | Shimano Tiagra 4700, long cage, 34T max cog |
| *Crank | Size: 49, 52 Shimano Tiagra 4700, 50/34, 170 mm length |
| Size: 54, 56 Shimano Tiagra 4700, 50/34, 172.5 mm length |
|
| Size: 58 Shimano Tiagra 4700, 50/34, 175 mm length |
|
| Bottom bracket | Shimano RS501 BSA |
| Cassette | Shimano 10-speed, 11-32T |
| Chain | Shimano Tiagra HG54, 10-speed |
| Max. chainring size | 1x: 50T, 2x: 50/34 |
Wheels
| Hub front | Formula RX-512 alloy, 6-bolt, 100×12 mm thru axle |
|---|---|
| Skewer front | Bontrager Switch chamfered thru axle, removable lever |
| Hub rear | Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142×12 mm thru axle |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Rim | Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve |
| Spokes | 14 g stainless steel, black |
| Tyre | Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700×32 mm |
| Max tyre size | 38 mm without mudguards, 35 mm with mudguards |
Components
| Saddle | Verse Short, steel rails, 145 mm width |
|---|---|
| *Seatpost | Size: 49 Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length |
| Size: 52, 54, 56, 58 Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length |
|
| *Handlebar | Size: 49 Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 38 cm width |
| Size: 52 Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 40 cm width |
|
| Size: 54, 56 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width |
|
| Size: 58 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 44 cm control width, 48 cm drops width |
|
| Size: 58 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
| *Stem | Size: 49 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
| Size: 52, 54 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
|
| Size: 56, 58 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length |
|
| Brake | Shimano Tiagra hydraulic disc |
| Brake rotor | Shimano RT66, 6-bolt, 160 mm |
| Rotor size | Max brake rotor sizes: 160 mm front and rear |
